door
Rear wheel
1
2
3
4
5
6
7
8
9
10
11
11
12
13
14
15
16
17
18
19
19
20
20
21
22
23
1
Tyre
0000000
Niet beschikbaar
2
Tubeless tyre valve
AP8201546
7,61€ Stukprijs incl. btw
3
Rear wheel
AP8108917
Niet beschikbaar
3
Rear wheel
AP8108706
Niet beschikbaar
4
Brake disc D190
AP8213231
51,67€ Stukprijs incl. btw
5
Screw w/ flange M8x30
AP8152288
4,09€ Stukprijs incl. btw
6
Rear wheel spacer
AP8125726
34,87€ Stukprijs incl. btw
7
Brake hanger plate cpl.
AP8134308
Niet beschikbaar
8
DAX flange nut M14x1,5
AP8152244
5,52€ Stukprijs incl. btw
9
Spring washer 14,5x24
AP8150471
6,22€ Stukprijs incl. btw
10
Screw w/ flange M8x25
AP8152287
4,64€ Stukprijs incl. btw
11
Ball bearing
AP8110083
Niet beschikbaar
12
Silent-block
AP8120970
Niet beschikbaar
13
Rear brake caliper D30
AP8113848
764,12€ Stukprijs incl. btw
14
Rear pads pair
AP8213462
Niet beschikbaar
15
F.antiwhistle plate-pair
AP8113677
25,91€ Stukprijs incl. btw
16
Pin+Brake spring
AP8213461
Niet beschikbaar
17
Brake caliper cover
AP8213224
Niet beschikbaar
18
Bleeder+cap
AP8113321
26,40€ Stukprijs incl. btw
19
Washer 10x14x1,6*
AP8113004
3,74€ Stukprijs incl. btw
20
Oil pipe screw
AP8113003
3,94€ Stukprijs incl. btw
21
Rear brake hose
AP8113704
73,80€ Stukprijs incl. btw
22
Cable-guide
AP8121856
15,60€ Stukprijs incl. btw
23
Brake caliper rev. kit
AP8213457
Niet beschikbaar
De schema's zijn uitsluitend ter informatie. Bij twijfel staan onze specialisten klaar om uw vragen te beantwoorden. Let er bij het toevoegen van een onderdeel aan uw winkelwagen op dat u de gewenste hoeveelheid selecteert. De vermelde stukprijs geldt voor één exemplaar van elk onderdeelnummer.
